| Model No. | Pixel Pitch | Display Size/MM | Cabinet size/MM | LED Type | Resolution/Dots/sqm | Module Size | Power Consumption | Brightness |
| Shelf300*60-1.2 | 1.2mm | 300*60mm | 308*68*21.5MM | SMD1010 | 694444 | 150*60MM | 16W | 600nits |
| Shelf600*60-1.2 | 1.2mm | 600*60mm | 608*68*21.5MM | SMD1010 | 694444 | 150*60MM | 32W | 600nits |
| Shelf900*60-1.2 | 1.2mm | 900*60mm | 908*68*21.5MM | SMD1010 | 694444 | 150*60MM | 48W | 600nits |
| Shelf1200*60-1.2 | 1.2mm | 1200*60mm | 1208*68*21.5MM | SMD1010 | 694444 | 150*60MM | 64W | 600nits |
| Shelf300*60-1.5 | 1.5mm | 300*60mm | 308*68*21.5MM | SMD1515 | 444444 | 150*60MM | 16W | 600nits |
| Shelf600*60-1.5 | 1.5mm | 600*60mm | 608*68*21.5MM | SMD1515 | 444444 | 150*60MM | 32W | 600nits |
| Shelf900*60-1.5 | 1.5mm | 900*60mm | 908*68*21.5MM | SMD1515 | 444444 | 150*60MM | 48W | 600nits |
| Shelf1200*60-1.5 | 1.5mm | 1200*60mm | 1208*68*21.5MM | SMD1515 | 444444 | 150*60MM | 64W | 600nits |
| Shelf300*60-1.8 | 1.875mm | 300*60mm | 308*68*21.5MM | SMD1515 | 284444 | 150*60MM | 16W | 600nits |
| Shelf600*60-1.8 | 1.875mm | 600*60mm | 608*68*21.5MM | SMD1515 | 284444 | 150*60MM | 32W | 600nits |
| Shelf900*60-1.8 | 1.875mm | 900*60mm | 908*68*21.5MM | SMD1515 | 284444 | 150*60MM | 48W | 600nits |
| Shelf1200*60-1.8 | 1.875mm | 1200*60mm | 1208*68*21.5MM | SMD1515 | 284444 | 150*60MM | 64W | 600nits |
