You are here: Home > DOOH LED Display Screen
| Model | LPS2 | LPS3 | LPS4 |
| Pixel pitch | 2.5mm | 3.076mm | 4mm |
| Screen size | 960x1760MM/640X1760MM | ||
| Pixel density(dots/㎡) | 16,000 | 105,688 | 62,500 |
| LED encapsulation | SMD1415 | SMD1921 | |
| Scan Method | 1/16 | 1/13 | 1/10 |
| Module size(mm) | 320(L)*160(W)mm | ||
| Contrast Ratio | 5000:1 | ||
| Viewing Angle | 1600/1100 | ||
| Grey Level | 16384 | ||
| Refresh rate | >960HZ | ||
| Brightness(cd/m2 ) | >5000NITS | ||
| Max.power consumption(W/M2) | <1000 | <1000 | <800 |
| Ave.power consumption(W/M2) | <300 | <300 | <240 |
| Voltage | AC100/240V 50/60Hz | ||
| Operating Temperature | -30~+50°C | ||
| Storage Temperature | -40~+80°C | ||
| Protection Level | IP65 | ||
| Application | Outdoor | ||
| LED Lifetime | 80,000hours | ||
| Blind Spot | <3PPM | <3PPM | <3PPM |
| Control method | WIFI/4G | ||
