960X960MM P4 Outdoor LED Display

Quick Details

960X960MM P4 Outdoor LED Display:

Pixel Pitch:4MM

Cabinet Material:Die-casting Aluminum Cabinet

Cabinet size:960X960MM

Refresh rate:1920Hz/3840Hz

Brightness:6000NITS

Power Consumption:800W/M2(MAX)

IC:MBI5124/MBI5153/ICN2037/SM16106

LED:KINGLIGHT LED/NATIONSTAR LED

LED CHIP:SANAN/EPISTAR

Cabinet weight:30KG/Cabinet

Control card:Nova Star/Linsn/Huidu/Colorlight

Application:Outdoor Rental/Fixed

Features:

▇Die-casting Aluminum Cabinet

▇Fast assemble and dismantle

▇Light weight and super slim

▇High refresh rate:>1920Hz

▇Anti-ghost line and tailer line design is available

▇Seamless connection

▇Application:Adverting,Stage,Events,TV Studio,Concerts,Trade Show etc.

▇Installation:Stand on ground,Fixed to the wall,Hanging

960X960MM P4 Outdoor LED Display Die-casting Aluminum Cabinet:
Module Parameters		Pixel pitch	4 mm
		Pixel Density	62500pixels/m2
		LED Shape	SMD 3in1/SMD1921
		LED Configuration	1R1G1B
		Module Resolution	80X40Ppixel
		Module Size	320X160MM
		Drive Method	1/8 constant current drive
Cabinet Parameters		Cabinet Resoltuion	240x240pixel
		Cabinet Size	960x960mm
		Cabinet Weight	30kg/cabinet
Display Parameters	Optical	Brightness	≥6000 cd/m2
		Viewing angle	H/V 160/160
		Best Viewing Distance	≥6 m
		Display Color	16.7 million
		Grey Scale	16bits/65536levels
	Power	Max power consumption	800 W/m2
		Ave power consumption	400 W/m2
		Working Voltage	220V / 110V
	Control system	Frame Frequency	60--85 HZ
		Refresh Rate	≥1920 HZ
		Data Transmission	CAT 5/ Optic Fiber
		Image Source	S-Video, PAL/ NTSC
		Controlling system	Linsn, Nova,Huidu,Colorlight
		Format	Video Compatibility DVI, VGA, composite
	Reliability	Working Temperature	-20~65 ℃
		Working Humidity	10-95% RH
		Life Span	100,000 Hours
		MTBF (Ave No Faliure Time)	5000 Hours
		Pixel failing Rate	0.01%
		IP Rate	IP65(Front)/IP54(Back)

The led display for Soutec LED With Anti-ghost and Tailer Design effect:
